Plasma Air Product Catalog

Our products include free-standing, portable, and in-duct models that are installed directly into the central HVAC system.

7000 Series

The PA 7000 series needlepoint air ion generators are commercial quality units intended for installation in air handling units (AHU), furnaces, or duct systems for commercial applications. The number of units and the quantity of the ionization outlets are dependent on the airflow in the system and the severity of the indoor air pollution problem.

Voltage

24V AC / 120V AC to 12V DC wall pack, 120V / 240V AC to 12V DC power supply, 241V / 277V AC to 12V DC power supply

Energy use

1, 2, 3, 4 watts

Capacity

Up to 6,000 CFM

No. of ionization outlets

1, 2, 3 or 4



Categories
Commercial

Plasma BAR Series

The Plasma BAR is a commercial quality, remote mounted needlepoint ion generator intended for installation in air handling units (AHU) and rooftop units (RTU). The Plasma BAR is available in lengths of 18 inches up to 96 inches in 6 inch increments to suit a wide variety of AHU or RTU size applications.

Voltage

24V AC or 12V DC. Power supply provided for 120V - 230V. Transformer provided for 277V.

Energy use

1.5 watts/LF

Capacity

Up to 20,000 CFM. Multiple BARs can be used.

No. of ionization outlets

1 outlet every 6.0"



Categories
Industrial

Plasma BAR-X Series

The Plasma BAR-X is a commercial quality, needlepoint ion generator intended for installation on the upstream side of the cooling coil in air handling (AHU) and rooftop units (RTU). The Plasma BAR-X is available in lengths of 18 inches up to 144 inches in custom lengths to suit a wide variety of AHU or RTU size applications dependent on the internal cross- sectional dimensions of the applicable AHU or RTU coil and the severity of the indoor air pollutants.

Voltage

120V AC / 230V AC

Energy use

60 VA

Capacity

Up to 30,000 CFM. Multiple BARs can be used.

No. of ionization outlets

1 outlet every 0.75"



Categories
Industrial

600 Series

The PA 600 series are needlepoint brush type ionizers producing an equal amount of positive and negative ions neutralizing harmful pollutants and odors. This self balancing unit is highly versatile as it may be installed at the fan inlet of an air handling unit, fan coil unit, PTAC, heat pump and a VRF ductless split system.

Voltage

12V DC / 24V AC / 120V AC / 240V AC

Energy use

< 1 watt

Capacity

Up to 2,400 CFM. Multiple units can be used.



Categories
Commercial

660 Series

The Plasma Air PA660 series are needlepoint brush type ionizers producing an equal amount of positive and negative ions neutralizing harmful pollutants and odors. This self-balancing unit is highly versatile as it may be installed at the fan inlet of an air handling unit, fan coil unit, PTAC, heat pump or a VRF ductless split system. The PA660 includes dry contacts which indicate ionizer functionality to a BAS (Building Automation System).

Voltage

12V DC / 24V AC / 120V AC / 240V AC

Energy use

< 1 watt

Capacity

Up to 2,400 CFM. Multiple units can be used.



Categories
Commercial

50 Series

The PA 50 series ion generators are 5 tube industrial quality units intended for installation in air handling units or in duct systems for commercial and industrial facilities. The number of units and the size of the ionization tubes are dependent upon the airflow in the system and the severity of the pollution problem.

Voltage

120V AC / 230V AC

Energy use

30, 50 watts

Capacity

Up to 10,000 CFM

100 Series

The PA100 series air ion generators are single tube commercial quality units intended for installation in air handling units (AHU), furnaces, or duct systems for residential, commercial and industrial applications. The number of units and the size of the ionization tubes are dependent on the airflow in the system and the severity of the pollution problem.

Voltage

120V AC / 230V AC

Energy use

8 watts

Capacity

Up to 3,000 CFM. Multiple units can be used.

200 Series

The PA 200 series air ion generators are two tube commercial quality units intended for installation in air handling units (AHU), furnaces, or duct systems for residential and commercial applications. The number of units and the size of the ionization tubes are dependent on the airflow in the system and the severity of the pollution problem.

Voltage

120V AC / 230V AC

Energy use

16 watts

Capacity

Up to 5,000 CFM. Multiple units can be used.

PlasmaPURE 600 Series

PlasmaPURE 600 provides safe and continuous air purification to the entire home using patented brush-style bipolar ionization technology.

Voltage

12V DC / 24V AC / 120V AC / 240V AC

Energy use

< 1 watt

Capacity

Up to 2,400 CFM. Multiple units can be used.



Categories
Residential
Applications

PlasmaPURE 7000 Series

PlasmaPURE 7000 provides safe and continuous air purification to the entire home using patented needlepoint bipolar ionization. Unit easily installs directly onto HVAC system ductwork.

Voltage

24V AC / 120V AC to 12V DC wall pack, 120V / 240V AC to 12V DC power supply, 241V / 277V AC to 12V DC power supply

Energy use

1, 2, 3, 4 watts

Capacity

Up to 6,000 CFM

No. of ionization outlets

1, 2, 3 or 4



Categories
Residential
Applications

PlasmaPURE AutoClean 1500

The PlasmaPURE AutoClean 1500 is a self-cleaning needlepoint ionizer that produces positive and negative ions that neutralize harmful pollutants and odors in the home.

Voltage

12V DC / 24V AC

Energy use

< 1 watt

Capacity

Up to 6,000 CFM. Multiple units can be used.



Categories
Residential
Applications

Novaerus Defend 1050

Designed for rapid remediation in large spaces and situations with high risk of infection, the Novaerus Defend 1050 (NV1050) uses patented ultra-low energy plasma technology combined with a triple-stage Camfil® filter system to provide a combined solution for air dis-infection and particle removal. Free-standing unit can be wheeled easily to point of care and plugs into any outlet.

Voltage

120V AC

Energy use

137 - 331 watts

Capacity

107 - 533 CFM. Up to 2000 SF. Multiple units can be used.



Categories
Residential
Commercial

Novaerus Protect 200 & 900

Designed for continuous air dis-infection and odor control in small indoor spaces, the Novaerus NV200 and NV900 use patented filter-free ultra-low energy plasma technology. Can be wall-mounted or placed on any surface with a stand and plugs into any outlet.

Voltage

120VAC

Energy use

20 watts

Capacity

Up to 900 SF. Multiple units can be used.



Categories
Residential
Commercial

Ceiling Scrubbers

The Ceiling Air Purification Scrubber is a complete air purification system integrating multilayer filtration, air purification, sterilization and air ionization. The unit contains several technologies including a washable pre-filter, electrostatic precipitator, HEPA filter, activated carbon filter, UVC lamps, photo-catalytic oxidizer, and a bipolar ion generator.

Voltage

120V AC / 230V AC

Energy use

155 watts

Capacity

Up to 300 CFM



Categories
Residential
Commercial

Monitoring

Devices to measure negative ions in ambient air (handheld) or in system (Duct or AHU mounted).

Capacity

Measurement range: 0 to 20,000 Negative Ions/cm3



Categories
Residential
Commercial
Industrial

Airflow Switches

A convenient method for powering and mounting a model 100 or 200 ionizer. Equipped with an integral pressure switch which closes at 0.05 Inch WG. Unit is mounted directly to metal duct with sheet metal screws and ionizer is mounted to unit with machine screws.

Voltage

120V AC / 230V AC

Energy use

20 watt max
